AOC E4 CU34E4CV computer monitor 86.4 cm (34") 3440 x 1440 pixels UltraWide Quad HD LCD Black

SKU
CU34E4CV
main product photo
Login for pricing
In stock
Screen size (inch) 34, Panel resolution 3440x1440, Max Refresh rate 120 Hz, Panel type VA, HDMI HDMI 2.0 x 2, DisplayPort DisplayPort 1.4 x 1, Sync technology (VRR) Adaptive Sync
Category: Computer Monitors
Boost productivity with the CU34E4CV 34" WQHD Ultrawide monitor
The CU34E4CV offers a 34" WQHD display with a 120Hz refresh rate, HDR10, and Hardware Anti-Blue Light for clear, comfortable viewing. Featuring Smart KVM, a 90W PD docking station, and a sleek, professional design, it's ideal for enhancing productivity and multitasking.
More Information
SKU CU34E4CV
EAN 4038986112864
Specification
Display
HDCPYes
Display brightness (typical)350 cd/m²
Screen shapeCurved
Display number of colours16.7 million colours
Native aspect ratio21:9
Pixel density109.68 ppi
DDC/CIYes
Maximum refresh rate120 Hz
sRGB coverage (typical)120.6%
HD typeUltraWide Quad HD
Display technologyLCD
Contrast ratio (dynamic)20000000:1
Viewing angle, horizontal178°
Viewing angle, vertical178°
Pixel pitch0.23175 x 0.23175 mm
Horizontal scan range30 - 190 kHz
Vertical scan range48 - 120 Hz
Viewable size, horizontal79.7 cm
Viewable size, vertical33.4 cm
Backlight typeW-LED
Display resolution3440 x 1440 pixels
Response time4 ms
Display diagonal86.4 cm (34")
Contrast ratio (typical)3500:1
Surface hardness3H
TouchscreenNo
High Dynamic Range (HDR) supportedYes
Panel typeVA
High Dynamic Range (HDR) technologyHigh Dynamic Range 10 (HDR10)
Screen curvature rating1500R
Display diagonal (metric)86.36 cm
LED backlightYes
Local dimmingYes
Response time measurement typeGTG (Gray to Gray)
Anti-glare screenYes
Audio
Built-in speaker(s)Yes
RMS rated power10 W
Performance
Built-in speaker(s)Yes
RMS rated power10 W
VESA Adaptive Sync supportYes
Low Blue Light technologyYes
Flicker-free technologyYes
Management features
Plug and PlayYes
Picture-in-PictureYes
Multimedia
Number of speakers2
Built-in speaker(s)Yes
RMS rated power10 W
Design
Market positioningOffice
Product colourBlack
Front bezel colourBlack
Frameless designYes
Ports & interfaces
Built-in USB hubYes
USB hub version2.0 / 3.2 Gen 1 (3.1 Gen 1)
USB upstream port typeUSB Type-B, USB Type-C
USB Type-A downstream ports quantity4
Headphone outYes
HDMI ports quantity2
DisplayPorts quantity1
HDCPYes
Headphone outputs1
HDMIYes
HDMI version2.0
DisplayPort version1.4
USB Power Delivery (USB PD)Yes
USB Power Delivery up to90 W
Number of USB Type-B upstream ports quantity1
Number of USB Type-C upstream ports quantity2
Built-in KVM switchYes
HDCP version1.4/2.2
Ethernet LANYes
Technical details
Height (without stand)365.4 mm
Depth (without stand)101.5 mm
Width (without stand)808.8 mm
Cable lock slotYes
HDMIYes
Product colourBlack
Front bezel colourBlack
Sustainability certificatesENERGY STAR, EPEAT, TCO
Doesn't containHalogen, Mercury, PVC/BFR
Warranty period5 year(s)
Compliance certificatesCB, CE, EAC, Federal Communications Commission (FCC), REACH, RoHS, TÜV mark, UKCA, WEEE
Power supply typeInternal
Weight (with stand)9.92 kg
Surface hardness3H
TouchscreenNo
Network
Ethernet LANYes
Ergonomics
VESA mountingYes
Cable lock slotYes
Panel mounting interface100 x 100 mm
SwivellingYes
Swivel angle range-180 - 180°
Tilt angle range-5 - 23°
Plug and PlayYes
Picture-in-PictureYes
Height adjustmentYes
Cable lock slot typeKensington
Cable managementYes
Tilt adjustmentYes
Adjustable height (max)18 cm
Power
Power supply typeInternal
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Power consumption (max)179 W
Power consumption (standby)0.5 W
Power consumption (typical)37 W
Power consumption (off)0.3 W
Input current2.5 A
Energy efficiency scaleA to G
Energy efficiency class (SDR)E
Energy efficiency class (HDR)G
Energy consumption (SDR) per 1000 hours25 kWh
Energy consumption (HDR) per 1000 hours46 kWh
Operational conditions
Non-operating altitude0 - 12192 m
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-25 - 55 °C
Operating relative humidity (H-H)10 - 85%
Storage relative humidity (H-H)5 - 93%
Operating altitude0 - 5000 m
Weight & dimensions
Height (without stand)365.4 mm
Depth (without stand)101.5 mm
Width (without stand)808.8 mm
Width (with stand)808.8 mm
Depth (with stand)252.2 mm
Height (with stand)581.6 mm
Weight (with stand)9.92 kg
Weight (without stand)7.16 kg
Package width930 mm
Package depth188 mm
Package height525 mm
Package weight13.6 kg
Packaging data
Package width930 mm
Package depth188 mm
Package height525 mm
Package weight13.6 kg
Cables includedAC, DisplayPort, HDMI, USB Type-C to USB Type-C
DisplayPort cable length1.8 m
HDMI cable length1.8 m
Packaging content
Cables includedAC, DisplayPort, HDMI, USB Type-C to USB Type-C
DisplayPort cable length1.8 m
HDMI cable length1.8 m
Sustainability
Sustainability certificatesENERGY STAR, EPEAT, TCO
Doesn't containHalogen, Mercury, PVC/BFR
Other features
Warranty period5 year(s)
Local dimmingYes
Compliance certificatesCB, CE, EAC, Federal Communications Commission (FCC), REACH, RoHS, TÜV mark, UKCA, WEEE
Height (without stand)365.4 mm
Depth (without stand)101.5 mm
Width (without stand)808.8 mm
Power consumption (max)179 W
HDMIYes
Surface hardness3H
USB Power Delivery up to90 W
Energy efficiency scaleA to G
Power supply typeInternal
Ethernet LANYes
TouchscreenNo
USB Power Delivery (USB PD)Yes
Front bezel colourBlack
Manufacturer AOC
