Specification |
Display |
---|
Display | LED | HDCP | Yes | Display brightness (typical) | 250 cd/m² | Display number of colours | 16.78 million colours | Native aspect ratio | 16:10 | DDC/CI | Yes | Display technology | LCD | Contrast ratio (dynamic) | 20000000:1 | Viewing angle, horizontal | 170° | Viewing angle, vertical | 160° | Pixel pitch | 0.282 x 0.282 mm | Aspect ratio | 16:10 | Viewable size, horizontal | 47.4 cm | Viewable size, vertical | 29.6 cm | Viewable size diagonal | 55.9 cm | Digital horizontal frequency | 30 - 83 kHz | Digital vertical frequency | 56 - 75 Hz | Separate H/V sync | Yes | Sync-on-green (SOG) | Yes | 3D | No | Supported graphics resolutions | 1680 x 1050 (WSXGA+) | Backlight type | W-LED | Display resolution | 1680 x 1050 pixels | Response time | 5 ms | Display diagonal | 55.9 cm (22") | Contrast ratio (typical) | 1000:1 | Touchscreen | No | Panel type | TFT | Colour gamut standard | sRGB | Audio |
---|
Built-in speaker(s) | Yes | RMS rated power | 3 W | Performance |
---|
Built-in speaker(s) | Yes | RMS rated power | 3 W | Mean time between failures (MTBF) | 30000 h | Built-in camera | No | Windows operating systems supported | Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 | Mac operating systems supported | Yes | Component video sync | Separate sync, Sync-on-green (SOG) | Management features |
---|
On Screen Display (OSD) | Yes | Number of OSD languages | 21 | On Screen Display (OSD) languages | Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Turkish, Ukrainian | Plug and Play | Yes | Multimedia |
---|
Number of speakers | 2 | Built-in speaker(s) | Yes | RMS rated power | 3 W | Built-in camera | No | TV tuner integrated | No | Design |
---|
Heavy metals free | Hg (mercury), Pb (lead) | Feet colour | Grey | Certification | CE Mark, FCC Class B, SEMKO, cETLus, BSMI, CU-EAC, EPA, TUV/GS, TUV Ergo, UKRAINIAN, WEEE | Product colour | Grey | Front bezel colour | Grey | Total amount of recyclable materials | 65% | Mean time between failures (MTBF) | 30000 h | Camera |
---|
Built-in camera | No | Ports & interfaces |
---|
USB hub version | 2.0 | USB Type-A downstream ports quantity | 2 | Headphone out | Yes | DVI port | Yes | VGA (D-Sub) ports quantity | 1 | DVI-D ports quantity | 1 | HDMI ports quantity | 0 | DisplayPorts quantity | 1 | HDCP | Yes | PC Audio in | Yes | AC (power) in | Yes | TV tuner |
---|
TV tuner integrated | No | Technical details |
---|
Height (without stand) | 349 mm | Depth (without stand) | 59 mm | Width (without stand) | 504 mm | Feet colour | Grey | Total amount of recyclable materials | 65% | Cable lock slot | Yes | On/off switch | Yes | Mean time between failures (MTBF) | 30000 h | Product colour | Grey | Recommended resolution | 1680 x 1050 @ 60 Hz | Recyclable packaging material | 100% | Front bezel colour | Grey | Sustainability certificates | EPEAT Gold, ENERGY STAR | Weight (with stand) | 5.2 kg | Touchscreen | No | Software |
---|
Windows operating systems supported | Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 | Mac operating systems supported | Yes | Ergonomics |
---|
VESA mounting | Yes | Cable lock slot | Yes | Panel mounting interface | 100 x 100 mm | LED indicators | Operation, Stand-by | Swivelling | Yes | Swivel angle range | -65 - 65° | Tilt angle range | -5 - 20° | Pivot | Yes | On Screen Display (OSD) | Yes | Pivot angle | 90 - 90° | Number of OSD languages | 21 | On Screen Display (OSD) languages | Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Turkish, Ukrainian | Plug and Play | Yes | Height adjustment | Yes | Cable lock slot type | Kensington | Tilt adjustment | Yes | Adjustable height (max) | 11 cm | On/off switch | Yes | Power |
---|
AC input voltage | 100 - 240 V | AC input frequency | 50 - 60 Hz | Power consumption (standby) | 0.3 W | Power consumption (typical) | 18.84 W | Power consumption (PowerSave) | 11.4 W | Operational conditions |
---|
Non-operating altitude | 0 - 12192 m | Operating temperature (T-T) | 0 - 40 °C | Storage temperature (T-T) | -20 - 60 °C | Relative humidity | 20 - 80% | Operating altitude | 0 - 3658 m | Weight & dimensions |
---|
Height (without stand) | 349 mm | Depth (without stand) | 59 mm | Width (without stand) | 504 mm | Width (with stand) | 504 mm | Depth (with stand) | 227 mm | Height (with stand) | 509 mm | Weight (with stand) | 5.2 kg | Weight (without stand) | 3.38 kg | Package width | 565 mm | Package depth | 186 mm | Package height | 391 mm | Package weight | 7.05 kg | Packaging data |
---|
Package width | 565 mm | Package depth | 186 mm | Package height | 391 mm | Package weight | 7.05 kg | Stand included | Yes | Manual | Yes | Packaging content |
---|
Stand included | Yes | Manual | Yes | Indication |
---|
LED indicators | Operation, Stand-by | Sustainability |
---|
Sustainability certificates | EPEAT Gold, ENERGY STAR | Other features |
---|
Heavy metals free | Hg (mercury), Pb (lead) | Display | LED | On/off switch | Yes | Mean time between failures (MTBF) | 30000 h | Certification | CE Mark, FCC Class B, SEMKO, cETLus, BSMI, CU-EAC, EPA, TUV/GS, TUV Ergo, UKRAINIAN, WEEE | TV tuner integrated | No | Recommended resolution | 1680 x 1050 @ 60 Hz | Recyclable packaging material | 100% | Height (without stand) | 349 mm | Depth (without stand) | 59 mm | Width (without stand) | 504 mm | Manual | Yes | Touchscreen | No | Front bezel colour | Grey | Recycling data |
---|
Total amount of recyclable materials | 65% | Post-consumer recycled plastic | 65% | Thin Client |
---|
Thin client installed | No | Certificates |
---|
Certification | CE Mark, FCC Class B, SEMKO, cETLus, BSMI, CU-EAC, EPA, TUV/GS, TUV Ergo, UKRAINIAN, WEEE |
|
