iiyama ProLite 17" Projective Capacitive 10pt touch screen with AG-coating
SKU
T1732MSC-B5AG
Category: Computer Monitors
Touch technology - Capacitive
This technology uses a sensor-grid of micro-fine wires integrated into the glass that covers the screen. Touch is detected because electrical characteristics of the sensor grid change when human finger is placed on the glass. Thanks to the glass overlay this technology is highly durable, and the touch function remains unaffected even if the glass is scratched. It offers perfect picture performance and will work with human finger (also latex gloved) and stylus-pen.
AG Coating
The anti-glare coating is used in professional-grade displays to help avoid issues with reflections and external light sources affecting colour reproduction, contrast and sharpness. It also makes the screen less susceptible to dust, grease and dirt marks.
IP54
The IP Code classifies how resistant a device is to foreign objects and moisture. IP54 means that the monitor will operate in dusty conditions, and will resist splashing water.
Scratch resistance
Scratch resistance is essential for touch solutions used in public places and schools. This is achieved thanks to a glass overlay covering the screen. It guarantees high durability of the touch function and even more importantly the touch function remains unaffected even if the glass is scratched.
Speakers
This LED monitor is equipped with two high quality stereo speakers.
The ProLite T1732MSC-B5AG 17" multi-touch screen is based on projected capacitive technology which thanks to a glass overlay covering the screen guarantees high durability, scratch-resistance and perfect picture performance. The anti-glare coating helps to avoid issues with reflections and external light sources affecting colour reproduction, contrast and sharpness. The touch function remains unaffected even if the glass is scratched. A solid and steady base supports the touchscreen with an adjustable stand offering full 90 degree positioning angles. Menu Buttons are located on the side of the screen which can be locked to prevent tampering and includes a handy function to deactivate the touchscreen for cleaning. In addition the edge-to-edge glass design creates an eye-catching finish with high light transmission guaranteeing perfect picture clarity and brilliant colours. Available in black and white.
| Display | |
|---|---|
| HDCP | Yes |
| Display brightness (typical) | 250 cd/m² |
| Screen shape | Flat |
| Display number of colours | 16.7 million colours |
| Native aspect ratio | 5:4 |
| Maximum refresh rate | 75 Hz |
| Display technology | LED |
| Viewing angle, horizontal | 170° |
| Viewing angle, vertical | 160° |
| Pixel pitch | 0.264 x 0.264 mm |
| Horizontal scan range | 31.4 - 60 kHz |
| Vertical scan range | 50 - 75 Hz |
| Aspect ratio | 5:4 |
| Viewable size, horizontal | 33.8 cm |
| Viewable size, vertical | 27.1 cm |
| Supported graphics resolutions | 1280 x 1024 (SXGA) |
| Display resolution | 1280 x 1024 pixels |
| Response time | 5 ms |
| Display diagonal | 43.2 cm (17") |
| Contrast ratio (typical) | 1000:1 |
| Touchscreen | Yes |
| Number of simultaneous touchpoints | 10 |
| Panel type | TN |
| Display diagonal (metric) | 43 cm |
| Touch technology | Multi-touch |
| Touchscreen technology | Projected capacitive system |
| Display brightness | 215 cd/m² |
| Response time measurement type | GTG (Gray to Gray) |
| Anti-glare screen | Yes |
| Audio | |
| Built-in speaker(s) | Yes |
| RMS rated power | 2 W |
| Performance | |
| Built-in speaker(s) | Yes |
| RMS rated power | 2 W |
| Megapixel (approx.) | 1.3 MP |
| AMD FreeSync | No |
| NVIDIA G-SYNC | No |
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Number of simultaneous touchpoints (Windows 7) | 10 |
| Management features | |
| Plug and Play | Yes |
| Multimedia | |
| Number of speakers | 2 |
| Built-in speaker(s) | Yes |
| RMS rated power | 2 W |
| Megapixel (approx.) | 1.3 MP |
| Design | |
| Product colour | Black |
| Front bezel colour | Black |
| International Protection (IP) code | IP54 |
| Camera | |
| Megapixel (approx.) | 1.3 MP |
| Ports & interfaces | |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| HDCP | Yes |
| HDMI | Yes |
| USB Touch port | Yes |
| Technical details | |
| Height (without stand) | 320 mm |
| Depth (without stand) | 54.5 mm |
| Width (without stand) | 387 mm |
| Cable lock slot | Yes |
| HDMI | Yes |
| Display viewable area (HxV) | 338 x 270.5 mm |
| Product colour | Black |
| Front bezel colour | Black |
| Power supply type | Internal |
| Weight (with stand) | 5.6 kg |
| Touchscreen | Yes |
| Number of simultaneous touchpoints | 10 |
| Software | |
|---|---|
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Ergonomics | |
| Wall mountable | Yes |
| VESA mounting | Yes |
| Cable lock slot | Yes |
| Panel mounting interface | 100 x 100 mm |
| Tilt angle range | -5 - 90° |
| Plug and Play | Yes |
| Cable lock slot type | Kensington |
| Cable management | Yes |
| Tilt adjustment | Yes |
| Power | |
| Power supply type | Internal |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (standby) | 1 W |
| Power consumption (typical) | 20 W |
| Power consumption (off) | 1 W |
| Energy efficiency scale | A to G |
| Energy efficiency class (SDR) | E |
| Energy consumption (SDR) per 1000 hours | 12 kWh |
| European Product Registry for Energy Labelling (EPREL) code | 373260 |
| Weight & dimensions | |
| Height (without stand) | 320 mm |
| Depth (without stand) | 54.5 mm |
| Width (without stand) | 387 mm |
| Width (with stand) | 387 mm |
| Depth (with stand) | 202 mm |
| Height (with stand) | 342 mm |
| Weight (with stand) | 5.6 kg |
| Packaging content | |
| Quick start guide | Yes |
| Sustainability | |
| European Product Registry for Energy Labelling (EPREL) code | 373260 |
| Packaging data | |
| Quick start guide | Yes |
| Other features | |
| Display viewable area (HxV) | 338 x 270.5 mm |
| International Protection (IP) code | IP54 |
| Height (without stand) | 320 mm |
| Depth (without stand) | 54.5 mm |
| Width (without stand) | 387 mm |
| Quick start guide | Yes |
| HDMI | Yes |
| Energy efficiency scale | A to G |
| Power supply type | Internal |
| Touchscreen | Yes |
| Number of simultaneous touchpoints | 10 |
| Front bezel colour | Black |
| Logistics data | |
| Harmonized System (HS) code | 85285210 |
